Car GPS Tracker TK116 Quad band Cut off fuel voice monitor 1 year free web-based GPS tracking system

Sidebar

Certifications

: Larger Image : Car GPS Tracker TK116 Quad band Cut off fuel voice monitor 1 year free web-based GPS tracking system

Minimum Order Quantity:	100 Piece/Pieces
Packaging Details:	Package box demensions:1309060(mm) Net weight:142g Gross weight:250g
Delivery Time:	1-2weeks
Payment Terms:	T/T
Supply Ability:	30,000 Piece/Pieces per Month

Detailed Product Description

GPS Tracker
Built-in GSM and GPS antennas
-Real-time tracking and burglar alarm
-SOS alarm and voice monitoring function

Product Description

Mini Vehicle GPS Tracker

1.check location via SMS
2.sos alarm and burgar alarm
3.voice monitor functions
4.SOS Smart GPS Car Vehicle Tracker

Products Introduction:

GSM 850/900/1800/1900 Quad bad
GPS chipset with high sensitivity, High integration density
Built-in high sensitivity GPS antenna, extra strong receptivity
The only one global vehicle device built in double antenna (GSM+GPS)
Built-in ON/OFF power, wide voltage input range
ACC detection, to upload status of vehicle operation
Be able to external connect cutoff relay to perform gas and electricity telecontrol
3 special numbers for SOS alarm and burglar alarm
Be able to external connect SOS alarm button for emergency call
Be able to external connect microphone to perform voice monitor
Built-in backup battery to perform (illegal)
Compatible with external connection of device serial port communication

Specification

GSM	850/ 900/ 1800/ 1900 MHz
GPRS	Class12,TCP/ IP build in GSM Module
GPS	MTK
GPS Channels	20
Tracking sensitivity	-159dBm
Acquisition sensitivity	-144dBm
Locating time cost	Hot start: <2 sec(open sky)
	Warm start: <15 sec
	Cold start: <38 sec(open sky)
Antenna	Built-in GSM quad band antenna, GPS high gain antenna
Battery	500mAh
Monitoring range	5M
Voltage input range	5-36 VDC
LED indicator	Three LED indicator: GPS-blue, GSM-green, Power-red
Dimensions	98.0(L)× 52.0(W)× 15.0(H)mm
Weight	80g
Application environment	Operating temperature: -25°C to +70°C
	Operating humidity: 5% to 95% non-condensing

Type	Gps Tracker
Use	Automotive
Screen Size	NO
Place of Origin	Guangdong, China (Mainland)
Brand Name	Diwei
Model Number	TK116
Acquisition sensitivity	-144dBm
Antenna	Built-in GSM quad band antenna, GPS high gain antenna
Battery	500mAh
GPS channels	20 channels
GSM Frequency	850/900/1800/1900 MHz
GPRS	Class12,TCP/ IP build in GSM Module
GPS	SIRF Star III
Operating humidity	5% to 95% non-condensing
Operating temperature	-25°C to +70°C
Tracking sensitivity	-159dBm

Price:	FOB USD 35~45 / Piece
Minimum Order Quantity:	5 Piece/Pieces gps tracker Samples available
Port:	Shenzhen
Packaging Details:	full package
Delivery Time:	1 to 3 day
Payment Terms:	L/C,T/T,Western Union,MoneyGram,paypal
Supply Ability:	10000 Piece/Pieces per Day Buy the more more discount

Shenzhen Diwei Communication Technology Co., Ltd.

Tel:0086-13631518992

Fax:0086-13631518992

Contact Person: Ms. Ada Ke
