Car alarm with gps tracking device Gt06
Built-in ON/OFF power, super-wide voltage input range(9-36V DC). Built-in vibration sensor, perform vehicle intelligent robbery protection. The only one global vehicle device built in double antenna (GSM+GPS). Compatible with external connection of device serial port communication.Be able to external connect a relay, remote control the vehicle gas and electricity.
Products Introduction:
- GSM 850/900/1800/1900 Quad bad
- GPS chipset with high sensitivity, High integration density
- Built-in high sensitivity GPS antenna, extra strong receptivity
- The only one global vehicle device built in double antenna (GSM+GPS)
- Built-in ON/OFF power, wide voltage input range
- Built-in vibration sensor, perform vehicle intelligent robbery protection
- ACC detection, to upload status of vehicle operation
- Be able to external connect cutoff relay to perform gas and electricity telecontrol
- 3 special numbers for SOS alarm and burglar alarm
- Be able to external connect SOS alarm button for emergency call
- Be able to external connect microphone to perform voice monitor
- Built-in backup battery to perform (illegal)
- Compatible with external connection of device serial port communication
Features:
|
GSM
|
850/ 900/ 1800/ 1900 MHz
|
|
GPRS
|
Class12,TCP/ IP build in GSM Module
|
|
GPS
|
SIRF Star III
|
|
GPS Channels
|
20
|
|
Tracking sensitivity
|
-159dBm
|
|
Acquisition sensitivity
|
-144dBm
|
|
Locating time cost
|
Hot start: <2 sec(open sky)
|
|
|
Warm start: <15 sec
|
|
|
Cold start: <38 sec(open sky)
|
|
Antenna
|
Built-in GSM quad band antenna, GPS high gain antenna
|
|
Battery
|
500mAh
|
|
Monitoring range
|
5M
|
|
Voltage input range
|
5-36 VDC
|
|
LED indicator
|
Three LED indicator: GPS-blue, GSM-green, Power-red
|
|
Dimensions
|
98.0(L)× 52.0(W)× 15.0(H)mm
|
|
Weight
|
80g
|
|
Application environment
|
Operating temperature: -25°C to +70°C
|
|
|
Operating humidity: 5% to 95% non-condensing
|
GSM Quad-band girdles the globe. High sensitive GPS chip (from USA). High integration density of waterproof design. Three special numbers for SOS alarm and burglar alarm. Built-in high sensitive GPS antenna, extra strong receptivity
Support ACC detection, to upload status of vehicle operation. Built-in backup battery to perform alarm when wire is cut illegally. Be able to external connect microphone to perform voice monitor. Be able to external connect SOS alarm button for emergency call.
